产品特点Productfeatures

    秉泰公司生产的美式电缆分接箱，以其优良的性能，规范化的设计，优美的外观，广泛应用于电缆配电网系统中的电缆化工程设备，在各大工业园区，居民小区，城市人口密集区，商业中心以及高层建筑等各种场所得到普遍认同。它以单向开门、横向多通母排为主要特点，具有宽度小，组合灵活、全绝缘、全密封等显著优点。按照额定电流一般可以分为600A主回路和200A支回路两种。600A主回路采作旋入式螺栓固定连接；200A分支回路采用拔插式连接且可以带负荷拔插。

    ZHEJIANG BINGTAI ACCESSORIES OF CABLES CO.,  LTD product American-style branch box.it have excellent performance. normalized design. graceful apperance, it apply widely to cabling engineering equipment of cable power distribution network system, There is wide recognition that our prodicts in the various big industrial park. residential communityurban population centre、business center and high-rise buildings etc. it have main feature that one-way to open the door. lateral multipass bus bar, it have significant advantages that small width. flexible combinationfull insulation. omnisel etc.according to current rating, can be div|ded int0 600A major loop and 200A loop generally. Fix and connect 600A maior loop with screw-in type bolt  200A branch loop adopt pull and plug type connection and can charged pull and plug

适应环境Adapt to the environment

●环境温度：最高气温+40℃，最低气温-30℃

Ambient temperature: maximum air temperature+40℃, minimum air temperature-30℃

●风速：相当34m/s（不大于700Pa）

Wind speed: amount to 34m/s(no more than 700 pa)

●湿度：日相对湿度平均值不大于95%：月相对湿度平均值不大于95%

Relative humidity:day relative humidity of the average is not greater than 95%:

month relative humidity Of the average is not greater than 95%

●防震：水平加速度不大于0 4m/s，垂直加速度不大于0.15m/s

Quakeproof:level acceleration is not grater than 0.4m/s,

vertical acceleration ls not greater than 0.15m/s

●安装地点倾斜度：不大干3°

Installation site slope: it is not more than 3°

●安装环境：周围空气应不受腐蚀性、可燃性气体、水蒸气等明显污染，安装地点无剧烈震动

installation envlronment:Ambient air should not be clearly polluted by corrosive.

combustible gases. water vapor, installation site is not violent vibration

洼：订购本产品超出上述条件规定时，请与本公司协商。

Note: When ordering the product is beyond the above conditions required,Please negotiate with our company
