高压电缆分支箱系列
欧式高压电缆分支箱
项目 参数 额定电压 12KV 额定电流 630A 一分钟工频耐压 42KV 雷电冲击耐压 105KV 十五分钟直流耐压 52KV 动稳定电流 52kA/0.3s 热稳定电流 20kA/3s 箱体防护等级 lp33 DFW欧式电缆分支箱是近几年
发布日期:2017-11-29 点击:1151次
  • 产品图片
  • 性能指标
  • 产品视频



欧式电缆分接箱是近年来广泛用于电力配网系统中的电缆化工程设备;它的主要特点是双向开门、利用对接套管作为连接母排,具有长度小、电缆排列清楚、三芯电缆不需大跨度交叉等显著优点。其所采用的电缆接头符合DIN47636标准。一般采用额定电流630A螺栓固定连接式电缆接头。

  European-style cable branch box apply widely to cabling engineering equipment in the cable distribution network system in recent years.it have main characteristic of two-way open the door.butt joint bushing as connection bus bar.it have the length short.cable permute clearly,Three core cable have significant advantages that need not large span cross.The cable joint measure up to DIK147636 standards,it "Ixed

connection type cable joint with the rated current 630 A bolt generally

适应环境Adapt to the environment

●环境温度:最高气温+40℃,最低气温-30℃

Ambient temperature:maximum air temperature+40℃,mnimum air temperature -30℃

●风速:相当34m/s(不大干700Pa)

Wind speed: amount to 34m/s(no more than 700 pa)

●湿度:日相对湿度平均值不大于95%,月相对湿度平均值不大于95%

Relative humidity:day relative humidity of the average is not greater than 95%;

month relative humidity of the average is not greater than 95%

●防震:水平加速度不大于0.4m/s,垂直加速度不大干0.15m/s

Ouakeproof:level acceieration is not grater than 0.4m/s,
